24V DC DIN Rail LED Drivers

SKU EL-NDR-240-24
Original price $102.00 - Original price $189.00
Original price
$102.00 - $189.00
Current price $102.00

Introducing our 24V DC DIN Rail LED Drivers, a cost-effective and slender solution designed for easy installation on TS-35/7.5 or TS-35/15 mounting rails. The streamlined body design not only enhances the aesthetics but also optimizes space utilization within cabinets. This series is engineered to accommodate a full range AC input from 90V AC to 264V AC and complies with BS EN/EN61000-3-2 standards.

Achieving up to 90% efficiency, these drivers can function seamlessly in ambient temperatures ranging from -20°C to 70°C, facilitated by air convection. Equipped with a constant current mode for overload protection, they are well-suited for various inductive or capacitive applications. The comprehensive protection features and compliance with industrial control apparatus standards (UL508, TUV BS EN/EN62368-1, etc.) position the NDR-240 as a highly competitive power supply solution for 24V DC LED lighting applications. Trust in the reliability and performance of our NDR-240 series for your illumination needs.

Key Features

  • Universal AC Input/ Full Range
  • Built-in active PFC function
  • Protections: Short
  • Protections: Short circuit/ Overload/ Over Voltage/ Over temperature
  • Cooling by free air convection
  • Can be installed on DIN rail TS-35/7.5 or 15
  • UL 508 (industrial control equipment) approved
  • BS EN/EN61000-6-2(BS EN/EN50082-2) industrial immunity level
  • 100% full load burn-in tested
  • High efficiency, Long life, and high reliability


  • For use with compatible Constant Voltage 24V DC LED lighting. Not for use with dimmers.
  • Industrial control system
  • Semiconductor fabrication equipment
  • Factory automation system


EL-NDR-240-24 Spec SheetEL-NDR-480-24 Spec Sheet
  • Input Voltage: 90-264V AC
  • Output Voltage: 24V DC
  • Power: 240, or 480 watts options
  • Dimmable: No
  • Over Load Protection: Yes
  • Over Temperature Protection: Yes
  • Short Circuit Protection: Yes
  • Power Method: Hardwiring
  • Dimensions: See product spec sheets
  • Environment: Dry Location
  • IP Rating: IP20
  • Rating: UL Listed, CUL Listed, RoHS, CE
  • Warranty: 3 Year Limited
