LED Die Cast Aluminum Well Lights

SKU EL-324-BK EL-MR16-5W-30K
Original price $36.56 - Original price $75.81
Original price
$36.56 - $75.81
Current price $36.56

When uplighting commercial projects with subterranean lighting, the EL-324 is unmatched. Its design provides subterranean fixtures with beauty and class. It is among one of our cast aluminum in-ground well lights that do not require a PVC Sleeve for burial. It carries a one-year warranty. The fixture is available in our Powder Coated Black or Brass Finish Options with a matching faceplate. This fixture can be mounted for in-ground direct burial use or concrete encasement. It is extremely energy efficient and will last many years.

Required: The LED In-Ground Well Light requires a 12V DC Driver. Sold separately.


  • Made with cast aluminum
  • Black or natural brass finish options
  • Clear and heat resistant flat glass
  • Top grade fixed ceramic bi-pin socket
  • Silicone “O” ring gasket on the adjustable fixture for watertight sealing
  • Can be mounted in-ground direct burial or concrete encasement
  • Pre-wired 3 feet of 18-2 SPT2 direct burial cord.
  • Limited one year warranty of fixture against manufacture’s defects
  • Voltage ranges are: 11V-12.5V (halogen), 9V-17V (LED)
  • Requires Low Voltage Transformer
  • Each fixture i supplied with 5W MR16 LED Bulb


  • Grazing
  • Up Lighting
  • Back Lighting
  • Patios
  • Garden Walls
  • Decks
  • Gazebos
  • Boating Docks


View Spec Sheet

  • Power: 5 watt
  • Input Voltage: 12V DC
  • LED Color Options: 3000K, 5000K,
  • Brightness: 400 Lumens
  • Dimensions: 3.88 in. D x 3.75 in. H
  • IP Rating: IP68
  • Bulb Included: Yes
  • Bulb Type: MR-16
  • Fixture Type: Low Voltage
  • Material: Brass
  • Environment: Wet or Dry Locations
  • Power Supplies: 12V DC Drivers, Sold Separately
  • Lifespan: ± 30,000 - 50,000 hours
