LED High Output Tape Lights 12V DC 16 ft Reel - Step 1 Dezigns

LED High Output Tape Lights 16 ft Reel

SKU EL-HO2-60K-16-12
$45.88 - $47.20
$47.20
$45.88 - $47.20
$47.20

LED High Output Flexible Tape Lights are made with commercial-grade SMD 5050 Chipsets. Featuring 90+ CRI with high output and even illumination and is perfectly designed for tradeshow decoration, exhibition lighting, retail display lighting, back-lighting applications, and more. It allows you to easily create and install lighting for almost any surface or object.

The High Output LED Tape Light is fully dimmable when used with LED Dimmable Drivers, see related products. It is UL-listed to ensure the durability and safety of the LED tape light's lifespan.

The LED High Output Strip Lights can be cut every 2 inches (12V DC LED Tape) or 4 inches (24V DC LED Tape) at its cut marking points, allowing you to cut pieces to the length desired.

 * Required: The LED Tape Light is designed to work exclusively with the specified voltage drivers. Using a driver with an incorrect voltage rating will affect the performance and longevity of the LED tape light. Verify the voltage rating of your LED tape light and select the appropriate driver accordingly.

Voltage Options:

  • 12V DC LED High Output Tape Light:
    • Requires a 12V DC LED driver for operation.
    • Ensure that the power supply matches the voltage specification to achieve optimal performance and prevent damage to the LED tape.
  • 24V DC LED High Output Tape Light:
    • Requires a 24V DC LED driver for operation.
    • Use a compatible 24V DC driver to ensure efficient and reliable operation of the LED tape light.

Key Features

  • Maintenance-free
  • Solid-State Construction
  • High shock and Vibration Resistance
  • SMD 5050 LED Chips are high-intensity, ultra-bright, and energy-efficient
  • No RF interference
  • Up to 50,000 hours of Lifespan
  • UL, ETL Listed

Applications

  • Decorative Lighting for Tradeshows, Exhibition, Retail Displays
  • Architectural lighting for corridors, canopies, archways, or windows
  • Downlighting or Uplighting Applications
  • Backlighting or Edge-Lighting
  • Under-cabinet, Under-Counter, or cove lighting
  • Custom DIY projects

Specifications

View 12V DC HO Tape Light Spec Sheet

View 24V DC HO Tape Light Spec Sheet

Brightness 400 Lumens/ft (12V DC)
1312 Lumens/meter (12V DC)
195 Lumens/ft (24V DC)
640 Lumens/meter (24V DC)
Power (Watts) 4.5 watt/ft(12V DC)
14.76 watt/meter(12V DC)
2.7 watt/ft(24V DC)
8.9 watt/meter(24V DC)
Input Voltage 12V or 24V DC
LED CCT & Colors 6000K Cool White (12V/24V DC)
4100K Natural White (12V/24V DC)
3000K Warm White (12V/24V DC)
2700K Extra Warm White (12V DC)
Red (12V DC)
Green (12V DC)
Blue (12V DC)
CRI 90+
IP Rating IP20
Environment Indoor Use - Dry Location
LED Beam Angle 120°
LED Density 18 LEDs/ft
300 LEDs/reel
LED Chip Size SMD 5050
LED Spacing 0.66 in / 16.7 mm
Length 16.4 ft / 5 meters long
Width 0.39 in / 10mm wide
Height 0.08 in / 2mm thick
Cutting Increment 2 in at cut marking (12V DC Tape Light)
4 in at cut marking (24V DC Tape Light)
Adhesive Backing 3M Adhesive
Manufacturer Elumalight
Rating UL, ETL, RoHS
Avg. Lifetime ± 30,000 - 50,000 hours
Warranty 3 years limited
Power Supplies
 12V DC Drivers
24V DC Drivers
Accessories LED Tape Light Accessories
