LED Standard Tape Lights 24V DC 12 in. Segment

$7.72
SKU EL-FLT-60K-12-24

The 24V DC LED Standard Output Flexible Tape Lights are made with commercial-grade 3528 SMD LED Chipsets to ensure our LED strips last longer and run cooler with high consistency and even illumination. It is perfectly designed for tradeshow decoration, exhibition lighting, retail display lighting, back-lighting applications, and more.

The LED Standard Tape Light 12" Segment is fully dimmable when used with LED Dimmable Drivers. It is UL listed to ensure the durability and safety of the LED tape light lifespan.

18 LED Chips per 12" segment and cuttable every 4” on specified cut marks. Each LED strip segment can be easily connected together for a solder-free installation. Available with various CCT and color options to choose from. The LED Standard Tape Light gives you the freedom to easily design and install without any soldering for almost any surface or object.

 * Required: Requires a non-dimming or dimming 24 volt DC driver.


Key Features

  • Maintenance-free
  • Solid-State Construction
  • High shock and Vibration Resistance
  • SMD 3528 LED Chips are high intensity, ultra-bright, and energy-efficient
  • No RF interference
  • Up to 50,000 hours Lifespan

Applications

  • Decorative Lighting for Tradeshows, Exhibition, Retail Displays
  • Architectural lighting for corridors, canopies, archways, or windows
  • Downlighting or Uplighting Applications
  • Backlighting or Edge-Lighting
  • Under-cabinet, Under-Counter, or cove lighting
  • Custom DIY projects

Specifications

 View Spec Sheet

Brightness 125 Lumens/ft
410 Lumens/meter
Power (Watts) 1.8 watt/ft
5.9 watt/meter
Input Voltage 24V DC
LED CCT & Colors 6000K Cool White
4100K Natural White
3000K Warm White
Red
Green
Blue
Amber
CRI 90+
IP Rating IP20
Environment Indoor Use - Dry Location
LED Beam Angle 120°
LED Density 18 LEDs/ft
300 LEDs/reel
LED Chip Size SMD 2835
LED Spacing 0.66 in / 16.7 mm
Length 12 in per segment
Width 0.31 in / 8mm wide
Height 0.06 in / 1.6 mm thick
Cutting Increment 4 in / 100.16 mm
at cut marking
Adhesive Backing 3M Adhesive
Manufacturer Elumalight
Rating UL, ETL, RoHS
Avg. Lifetime ± 30,000 - 50,000 hours
Warranty 3 years limited
Power Supplies
24V DC Drivers
Accessories LED Tape Light Accessories
